1321579CH Marathon Special Products Power Distribution Blocks, 132 Series
MFG #:
1321579CH
Splicer Block, 1-P, 175A, Bx/Bx, Line: (1)2/0-14AWG Box Lug, Load: (1)2-14AWG Box + (1)1/4in. Q.C.
Specifications
| Manufacturer Part Number | 1321579CH |
|---|---|
| Manufacturer | Marathon Special Products |
| Product Series | 132 |
| Family Series | Marathon Special Products Power Distribution Blocks, 132 Series |
| Number of Poles | 1 |
| AC Voltage | 600 VAC |
| Current Rating | 175 A |
| Number of Inputs per Pole | 1 |
| Number of Outputs per Pole | 2 |
| Electrical Connection | Box Lug/Quick Connect |
| Mounting | DIN Rail/Panel Mount |
| Line Side Wire Range | 2/0-14 AWG |
| Output Wire Range | (1) 2-14 AWG; (1) 1/4 " Quick Connect |
| Cover Included | Yes |
| Composition | Phenolic |
| Color | Black |
| Approvals | CE, CSA, UL |
| Net Weight | 0 lbs |
| Gross Weight | 0 lbs |
Description
Power Distribution Blocks, 132 Series
Item #
1321579CH
Splicer Block, 1-P, 175A, Bx/Bx,
132 Series Information
- 115 to 1680 Amps
- 600 Volts AC/DC
- Flexible Stranded Wire Compliant
- Snap‑On Cover Type Available
