Specifications
| Manufacturer Part Number | 140203.00 |
|---|---|
| Manufacturer | Leeson |
| Product Series | Agricultural Duty |
| Family Series | Leeson Motors, Agricultural Duty Series |
| Type | Agricultural Duty |
| Horsepower | 5 hp |
| Speed | 1,800 RPM |
| RPM | 1,800 RPM |
| Number of Poles | 4 |
| NEMA Frame | 215T |
| Nominal Voltage | 240 VAC |
| Enclosure | Totally Enclosed Fan Cooled |
| Mounting | C-Face Footed |
| Service Factor | 1.15 |
| Composition | Steel |
| Length | 18.71 " |
| Approvals | CSA, UL |
| Net Weight | 0 lbs |
| Gross Weight | 0 lbs |
Description
Motors, Agricultural Duty Series
Item #
140203.00
Motor, 5HP, /230V, 1740RPM TEFC Farm
Agricultural Duty Series Information
- Gasketed capacitor cases and conduit box covers
- Meets or exceeds NEMA service factors
- Single phase and three phase designs
- Double sealed bearings
- Condensate drains on general purpose Ag motors
- Low temperature manual overload protected
- High and extra high starting torque ratings
- UL recognized component listing and CSA certified
