Series
6J30A1B Marathon Special Products Fuseblocks & Holders, CLASS J Series
MFG #:
6J30A1B
Fuseblock, 1-Pole, 30A/600V, J, Box Lug Terminals, DIN Mountable, UL Listed, CSA Certified
Specifications
| Manufacturer Part Number | 6J30A1B |
|---|---|
| Manufacturer | Marathon Special Products |
| Product Series | CLASS J |
| Family Series | Marathon Special Products Fuseblocks & Holders, CLASS J Series |
| Current Rating | 30 A |
| Voltage | 600 V |
| Poles | 1 |
| Fuse Type | Class J |
| Class | J |
| Connection Type | Box Lug |
| Mounting | DIN Rail |
| Composition | Thermoplastic |
| Trip Indicator | No |
| Reinforced | No |
| Enclosed | No |
| Touch Safe | No |
| Approvals | CE, CSA, UL |
| H x W x D | 1.95 " x 1.16 " x 3.38 " |
| Net Weight | 0.12 lbs |
| Gross Weight | 0.12 lbs |
Description
Fuseblocks & Holders, CLASS J Series
Item #
6J30A1B
Fuseblock, 1-Pole, 30A/600V, J,
CLASS J Series Information
- 30~600 Amps
- 600 Volts
- 1~3 Poles (Expanders Available)
- DIN Rail or Panel Mount
- Various Terminal Types
