Specifications
| Country of Origin | Japan |
|---|---|
| Manufacturer Part Number | AOLFW29911D-G-12V |
| Manufacturer | IDEC |
| Product Series | TW |
| Family Series | IDEC Switches, TW Series |
| Illuminated | Yes |
| Operation | Maintained |
| Mounting | 22 mm |
| Contacts | 1NO, 1NC |
| Max Voltage | 600 VAC, 600 VDC |
| Current Rating | 10 A |
| Bezel | Metal Round |
| Lamp Type | LED |
| Nominal Lamp Voltage | 12 VAC, 12 VDC |
| Lens/Button Shape | Round Extended |
| Operator Color | Green |
| Terminal Type | Screw |
| Protection Rating | IP65 |
| Approvals | CE, CSA, UL |
| H x W x D | 1.18 " x 1.46 " x 3.52 " |
| Net Weight | 0.1881 lbs |
| Gross Weight | 0.1881 lbs |
Description
Switches, TW Series
Item #
AOLFW29911D-G-12V
Pushbutton, Maint, Grn, Ext, 12V
TW Series Information
- 22mm Mounting Size
- Incandescent or LED Types
- Standard Screw Terminals
- NEMA 1,2,3,3R,3S,4,4X,5,12,13
- UL; CSA; CE Approvals
- Corrosion Resistant Chrome Bezel
- Fracture‑Resistant Nylon Body
Documents & Resources Links
Videos
Added to Cart
AOLFW29911D-G-12V IDEC Switches, TW Series, Pushbutton, Maint, Grn, Ext, 12V
Series TW
MFG #:
AOLFW29911D-G-12V
Pushbutton, Maint, Grn, Ext, 12V Direct, 22mm Mounting, LED, 1NO/1NC Contact Blocks, Full Shroud
