Specifications
| Country of Origin | Japan |
|---|---|
| Manufacturer Part Number | AYLW49911D-W-6V |
| Manufacturer | IDEC |
| Product Series | TW |
| Family Series | IDEC Switches, TW Series |
| Illuminated | Yes |
| Operation | Push-Pull |
| Mounting | 22 mm |
| Operator Size (mm) | 40 mm |
| Contacts | 1NO, 1NC |
| Max Voltage | 600 VAC, 600 VDC |
| Current Rating | 10 A |
| Bezel | Metal Round |
| Lamp Type | LED |
| Nominal Lamp Voltage | 12 VAC, 6 VDC |
| Lens/Button Shape | Mushroom |
| Operator Color | White |
| Terminal Type | Screw |
| Protection Rating | IP65 |
| Approvals | CE, CSA, UL |
| H x W x D | 1.18 " x 1.46 " x 3.52 " |
| Net Weight | 0.2313 lbs |
| Gross Weight | 0.2313 lbs |
Description
Switches, TW Series
Item #
AYLW49911D-W-6V
P/B 22MM P/PULL LED F/VOLT 1NO1NC
TW Series Information
- 22mm Mounting Size
- Incandescent or LED Types
- Standard Screw Terminals
- NEMA 1,2,3,3R,3S,4,4X,5,12,13
- UL; CSA; CE Approvals
- Corrosion Resistant Chrome Bezel
- Fracture‑Resistant Nylon Body
Documents & Resources Links
Videos
Added to Cart
AYLW49911D-W-6V IDEC Switches, TW Series, P/B 22MM P/PULL LED F/VOLT 1NO1NC
Series TW
MFG #:
AYLW49911D-W-6V
P/B 22MM P/PULL LED F/VOLT 1NO1NC WHITE
