Specifications
| Manufacturer Part Number | B050-0482-1 |
|---|---|
| Manufacturer | Micron Industries |
| Product Series | ImperviTRAN |
| Family Series | Micron Industries Transformers, ImperviTRAN Series |
| Phase | 1 |
| Type | Control |
| VA Rating | 50 VA |
| Primary Voltage | 208 V, 220 V, 230 V, 240 V, 277 V, 347 V, 380 V, 400 V, 415 V, 416 V, 440 V, 460 V, 480 V, 500 V, 550 V, 575 V, 600 V |
| Secondary Voltage | 85 V, 100 V, 110 V, 115 V, 120 V, 125 V, 127 V, 130 V |
| Enclosed | No |
| Primary Fuseholder | Optional |
| Secondary Fuseholder | Optional |
| Termination | Integrally Molded Terminal Blocks |
| Cover Included | Optional |
| Insulation Class | Class A |
| Approvals | CSA, UL |
| H x W x D | 3.45 " x 3.50 " x 3.85 " |
| Net Weight | 4.125 lbs |
| Gross Weight | 4.43 lbs |
Description
Transformers, ImperviTRAN Series
Item #
B050-0482-1
ImperviTRAN 50 VA, 208-600 Primary,
ImperviTRAN Series Information
- Epoxy Encapsulated Coil
- Corrosion‑Protected Windings and Solder
- Molded‑In Terminals and Terminal Barriers
- Pre‑Installed Mounting Holes
- Optional Secondary Fuse Clips Available
- Meets UL and cUL
