B100-2002-1
Micron Industries Transformers, ImperviTRAN Series
Product images are for illustration purposes only. Please review specifications and documentation for exact product details.
B100-2002-1 Micron Industries Transformers, ImperviTRAN Series
ImperviTRAN 100 VA, 208/230/460
MFG Item Number
B100-2002-1
Series
More specs
This item cannot be canceled or returned
Orders placed by 5:00pm Eastern time will ship today. If you would like to pick up your order, select Will Call during checkout if it is available.
Description
Transformers, ImperviTRAN Series
Item #
B100-2002-1
ImperviTRAN 100 VA, 208/230/460
ImperviTRAN Series Information
- Epoxy Encapsulated Coil
- Corrosion‑Protected Windings and Solder
- Molded‑In Terminals and Terminal Barriers
- Pre‑Installed Mounting Holes
- Optional Secondary Fuse Clips Available
- Meets UL and cUL
Specifications
| Manufacturer Part Number | B100-2002-1 |
|---|---|
| Manufacturer | Micron Industries |
| Product Series | ImperviTRAN |
| Family Series | Micron Industries Transformers, ImperviTRAN Series |
| Description | ImperviTRAN 100 VA, 208/230/460 Primary, 24/115 Secondary |
| Phase | 1 |
| Type | Control |
| VA Rating | 100 VA |
| Primary Voltage | 208 V, 230 V, 460 V |
| Secondary Voltage | 115 V, 24 V |
| Enclosed | No |
| Primary Fuseholder | Optional |
| Secondary Fuseholder | Optional |
| Termination | Integrally Molded Terminal Blocks |
| Cover Included | Optional |
| Insulation Class | Class A |
| Approvals | UL |
| H x W x D | 3.70 " x 3.75 " x 4.55 " |
| Net Weight | 6.45 lbs |
| Gross Weight | 6.635 lbs |
