Product images are for illustration purposes only. Please review specifications and documentation for exact product details.
Series
B7-30-10-03 ABB Contactors, B Series
MFG #:
B7-30-10-03
The B7-30-10 mini contactor is a compact 3 pole contactor with 1 auxiliary contact and screw terminals. They are ideally suited for applications where reliability is a must and space is at a premium. Mini contactors are used in residential buldings,
Specifications
| Manufacturer Part Number | B7-30-10-03 |
|---|---|
| Manufacturer | ABB |
| Product Series | B |
| Family Series | ABB Contactors, B Series |
| Nominal Coil Voltage | 48 VAC |
| Coil Voltage | 48 VAC |
| Coil Type | Magnetic |
| Poles | 3NO |
| Auxiliary Contact | 1NO |
| Termination | Screw |
| General Purpose (AC1) | 16 A |
| UL Motor Switching (AC3) | 9.6 A |
| H x W x D | 2.13 " x 4.53 " x 11.02 " |
| Net Weight | 1.0007 lbs |
| Gross Weight | 4.012 lbs |
Description
Contactors, B Series
Item #
B7-30-10-03
B7-30-10 MINI CONTACTOR 48V
B Series Information
- Up to 5,5 kW ‑ 400 V AC‑3, 5 hp ‑ 480V, 20 A ‑ 400 V AC‑1 and 16 A ‑ General Use
- 3 Types of Connections: Screw, Soldering Pins, Flat Pins
- Built‑in Mechanical Interlock Available
- Integrated Protective Circuit with Diodes, Additional Surge Suppressor
- Special Version with 1.4 W Coil Consumption for Direct Connection to PLC
