C25DND2151T Eaton Contactors, C25 Series
OP N-R 2P 15ADPCNT SCR/PP W/QC24DC CL
MFG Item Number
C25DND2151T
Eaton
main product photo

Product images are for illustration purposes only. Please review specifications and documentation for exact product details.

C25DND2151T Eaton Contactors, C25 Series

OP N-R 2P 15ADPCNT SCR/PP W/QC24DC CL
MFG Item Number
C25DND2151T
Eaton
Series
C25
More specs
This item cannot be canceled or returned

Orders placed by 5:00pm Eastern time will ship today. If you would like to pick up your order, select Will Call during checkout if it is available.
Request Lead Time

Description

Contactors, C25 Series
Item #
C25DND2151T
OP N-R 2P 15ADPCNT SCR/PP W/QC24DC CL

C25 Series Information

  • 24~480 VAC Coils
  • Up to 7‑1/2 HP @ 230V
  • Up to 5.5 KW @ 230V
  • UL; CSA Certified; IEC
  • Up to 50 Amps
Definite Purpose Contactors are electrically operated switching devices specifically designed for the heating, ventilation, air conditioning and refrigeration (HVACR) industry. Suitable for a wide range of other low‑cycle duty applications requiring low cost switching of single and three‑phase loads.
  • Quick Connect Terminals
  • Open Enclosure
  • Double Break Contacts
  • Class B Magnetic Coil

Links

Specifications

Specifications
Manufacturer Part Number C25DND2151T
Manufacturer Eaton
Product Series C25
Family Series Eaton Contactors, C25 Series
Description Eaton definite purpose contactor, Quick, 15A, 24 Vdc, Open with metal mounting plate, 15-50A, two- and three-pole, 15A, Contactor, Two-pole, 20A, Screw/pressure plate and quick connect terminals side-by-side, Non-reversing
Nominal Coil Voltage 24 VDC
Coil Voltage 24 VDC
Inductive Current Rating 15 A
Poles 2NO
Termination Pressure Plate, Quick Connect, Screw
Enclosure Open
Resistive Rating 20 A
Approvals CSA, UR
Net Weight 1.1 lbs
Gross Weight 1.19 lbs
