C25DND225A Eaton Contactors, C25 Series

MFG #:

C25DND225A

Eaton definite purpose contactor, Non-reversing contactors and starters C306,Compact, two-pole , Open with metal mounting plate ,Binding head screw and quick connect terminals side-by-side ,50A,110â€“120 Vac, 50/60 Hz ,Global Listed

View Full Specs

Skip to the end of the images gallery

Product images are for illustration purposes only. Please review specifications and documentation for exact product details.

Skip to the beginning of the images gallery

Series

C25

C25DND225A Eaton Contactors, C25 Series

Name: C25DND225A Eaton Contactors, C25 Series
Brand: Eaton
SKU: C25DND225A-CHGP
Price: 107.18 USD
Availability: BackOrder

MFG #:

C25DND225A

View Full Specs

Request Lead Time

Qty

Compare

This item cannot be canceled or returned

View Alternative Products

Specifications

Specifications
Country of Origin	China
Manufacturer Part Number	C25DND225A
Manufacturer	Eaton
Product Series	C25
Family Series	Eaton Contactors, C25 Series
Nominal Coil Voltage	120 VAC
Coil Voltage	110-120 VAC
Inductive Current Rating	25 A
Coil Type	Magnetic
Poles	2NO
Frame Size	D
Termination	Pressure Plate, Quick Connect, Screw
Shunt	No
Enclosure	Open
Resistive Rating	35 A
Approvals	CSA, UR
H x W x D	2.60 " x 3.80 " x 4.00 "
Net Weight	0.9 lbs
Gross Weight	0.9 lbs

Alternatives

Compare available alternatives using the specifications that matter for this product.

Alternatives comparison
Image	Part	Description	Series	Nominal Coil Voltage	Price	Action
	C25DND330A	Eaton definite purpose contactor, Quick, 30A,110-120 Vac, 50/60 Hz, Open with metal mounting plate, 15-50A, two- and three-pole, 30A, Contactor, Three-pole, 40A, Screw/pressure plate and quick connect terminals side-by-side, Non-reversing	C25	120 VAC	Price unavailable
	C25DND325A	Eaton definite purpose contactor, Quick, 25A, 110-120 Vac, 50/60 Hz, Open with metal mounting plate, 15-50A, two- and three-pole, 25A, Contactor, Three-pole, 35A, Screw/pressure plate and quick connect terminal side-by-side, Non-reversing	C25	120 VAC	Price unavailable

Accessories

Compare compatible accessories for this product.

Accessories comparison
Part	Description	Series	SKU	Price
C320KG1	Side Mounted Auxiliary Contact, Pressure plate, 1NO, For 15-75A	Eaton Contactors	C320KG1-CHGP	Price unavailable
C320KG2	Side Mounted Auxiliary Contact, Pressure plate, 1NC	Eaton Contactors	C320KG2-CHGP	Price unavailable
C320KG3	1NO-NC AUX CONT FOR 15-75A DP CONT	Eaton Contactors	C320KG3-CHGP	Price unavailable
C320KG4	Side Mounted Auxiliary Contact, Pressure plate, 2NO	Eaton Contactors	C320KG4-CHGP	Price unavailable
C320KG5	Side Mounted Auxiliary Contact, Pressure plate, 2NC	Eaton Contactors	C320KG5-CHGP	Price unavailable
