CNT60P2FG
MFG #:
CNT60P2FG
Specifications
| Country of Origin | Mexico |
|---|---|
| Manufacturer Part Number | CNT60P2FG |
| Manufacturer | US Motors |
| Family Series | US Motors Motors |
| Type | Coolant Pump |
| Horsepower | 60 hp |
| Kilowatts | 44.7 kW |
| Speed | 1,785 RPM |
| RPM | 1,785 RPM |
| Number of Poles | 4 |
| Phase | 3 |
| Frequency | 60 Hz |
| NEMA Frame | 364HP |
| AC Voltage | 460 VAC |
| Nominal Voltage | 480 VAC |
| Enclosure | Totally Enclosed Fan Cooled |
| Mounting | Vertical |
| Current Rating | 69 A |
| Composition | Cast Iron |
| Net Weight | 925 lbs |
| Gross Weight | 925 lbs |
Description
Motors, Series
Item #
CNT60P2FG
Motor, 60 HP, 1800 RPM, 364HP
