CS10.481 Puls Power Supplies, Dimension Series

MFG #:

CS10.481

Power Supply, 48VDC, 5A, 1PH, 240W, 100-120/200-240VAC Input, 124mmHx60mmWx117mmD, Screw Terminal

Product images are for illustration purposes only. Please review specifications and documentation for exact product details.

Series

Dimension

CS10.481 Puls Power Supplies, Dimension Series

Name: CS10.481 Puls Power Supplies, Dimension Series
Brand: Puls
SKU: CS10.481-PULS
Price: 498.15 USD
Availability: InStock

MFG #:

CS10.481

Power Supply, 48VDC, 5A, 1PH, 240W, 100-120/200-240VAC Input, 124mmHx60mmWx117mmD, Screw Terminal

Qty

This item cannot be canceled or returned

Specifications

Specifications
Country of Origin	China
Manufacturer Part Number	CS10.481
Manufacturer	Puls
Product Series	Dimension
Family Series	Puls Power Supplies, Dimension Series
Power	240 W
Nominal Input Voltage	120 VAC, 240 VAC
AC Voltage	100-120 VAC, 220-240 VAC
Input Frequency	47-63 Hz
Phase	1
Nominal Output Voltage	48 VDC
Output VDC	48-52 VDC
Output Current	5 A
Number of Outputs	1
Mounting	DIN Rail
Enclosed	Yes
Encapsulated	No
Output Voltage Adj.	Yes
Overvoltage Protection	Yes
Overload Protection	Yes
Short Circuit Protection	Yes
Power Factor Correction	No
Parallel Operation	No
Remote Sensing	No
Remote On/Off Control	No
Operating Temperature	-13-158 °F
Approvals	CCC, CE, cURus, UL1604 CLASS 1 DIV 2, UL508, UL60950
H x W x D	3.66 " x 5.51 " x 5.91 "
Net Weight	1.5431 lbs
Gross Weight	1.7637 lbs

Accessories

Compare compatible accessories for this product.

Accessories comparison
Part	Description	Mounting	Series	Price
YRM2.DIODE	REDUNDANCY MODULE WITH DIAGNOSTICS	DIN Rail	Dimension	Price unavailable
ZM1.WALL	MOUNTING BRACKET, (pkg / 2pcs) FOR PANEL MTG Q SERIES POWER SUPPLY			Price unavailable
ZM13.SIDE	MOUNTING BRACKET, FOR SIDE MOUNTING Q SERIES POWER SUPPLIES			Price unavailable
