Specifications
| Country of Origin | Mexico |
|---|---|
| Manufacturer Part Number | DVSW0012E |
| Manufacturer | MTE |
| Product Series | dV Sentry |
| Family Series | MTE Filters, dV Sentry Series |
| Current Rating | 12 A |
| Watts Loss | 67 W |
| Voltage | 380-600 VAC |
| Frequency | 50 Hz, 60 Hz |
| Motor HP | @ 380V: 7.5 hp, @ 480V: 7.5 hp, @ 550-600V: 10 hp |
| Enclosed | Yes |
| NEMA Rating | NEMA 3R |
| Approvals | CE, CSA, cUL, RoHS, UL |
| H x W x D | 12.00 " x 10.90 " x 15.50 " |
| Net Weight | 24 lbs |
| Gross Weight | 24 lbs |
Description
Filters, dV Sentry Series
Item #
DVSW0012E
Filter, dv/dt, 12A, 480-600V, 60Hz
dV Sentry Series Information
3-in-1 Protection
- Patented core design delivers the most advanced technology for the market
- PROVEN 50% + common mode voltage reduction
- Rise time reduction lowers motor heating, and meets NEMA MG 1-1998 Section 31 motor standards
- Peak voltage protection when voltage spikes reach dangerous levels
Problems protected by dV Sentry:
- Damage to motor bearings
- Unexpected ground fault trips
- Erratic behavior of VFDs and PLCs
- Premature motor insulation failure
- Cable damage
The unique triple defense core of the dV Sentry filters power through the outer core and reduces common mode voltage by over 50 percent. Additionally, power filters through the inner core and reduces rise time, and gives peak voltage protection. Available in voltages from 380V to 600V, 50/60Hz with currents 3A to 600A and are rated from NEMA ½ and NEMA 3R.
Documents & Resources Links
Added to Cart
DVSW0012E MTE Filters, dV Sentry Series, Filter, dv/dt, 12A, 480-600V, 60Hz
Series dV Sentry
MFG #:
DVSW0012E
Filter, dv/dt, 12A, 480-600V, 60Hz, NEMA3R, 380V, 50Hz
