EGE3050FFG Eaton Circuit Breakers, G Series
E 3P 50A 25kA 415480V FXD therm FXD mag
MFG Item Number
EGE3050FFG
Eaton
main product photo

Product images are for illustration purposes only. Please review specifications and documentation for exact product details.

EGE3050FFG Eaton Circuit Breakers, G Series

E 3P 50A 25kA 415480V FXD therm FXD mag
MFG Item Number
EGE3050FFG
Eaton
Series
G
More specs
This item cannot be canceled or returned

Orders placed by 5:00pm Eastern time will ship today. If you would like to pick up your order, select Will Call during checkout if it is available.
Request Lead Time

Description

Circuit Breakers, G Series
Item #
EGE3050FFG
E 3P 50A 25kA 415480V FXD therm FXD mag

G Series Information

  • Compact Design Frees up Panel Space
  • Common Field‑Fit Internal Accessories Make Installation and Custom Configuration Easy
  • Advanced Trip Unit Functionality Offers a Wide Range of Adjustment for Maximum Flexibility
  • Features High‑Speed "Blow‑Open" Action
  • Mounting Hardware and Lugs are Included for Convenience

Eaton Series G molded case circuit breakers provide increased performance in considerably less space than standard circuit breakers or comparable fusible devices. The "G" signifies global applications: Series G circuit breakers are marked with UL, CSA, CE, IEC and KEMA KEUR listings. The Series G family includes five frame sizes in ratings from 15 to 2500 amperes. Series G offers a choice of several interrupting capacities up to 200 kA at 480 volts AC (200 kA at 240 volts AC).


Links

Videos

Specifications

Specifications
Country of Origin Dominican Republic
Manufacturer Part Number EGE3050FFG
Manufacturer Eaton
Product Series G
Family Series Eaton Circuit Breakers, G Series
Description Eaton Series G molded case circuit breaker, EG-frame, EG, Fixed thermal, Fixed magnetic trip, Three-pole, 50 A, 600Y/347 Vac, 35 kAIC at 240 Vac, 25 kAIC at 480 Vac, 18 kAIC at 600Y/347 Vac, Line and load, 50/60 Hz
Poles 3
Current Rating 50 A
Max Voltage 480 VAC
Trip Unit Fixed Thermal / Fixed Magnetic
Mounting DIN Rail
Terminal Type Box Terminal
Auxiliary Switch Optional
Shunt Trip Optional
Undervoltage Release Optional
UL Standard 489
Approvals CE, CSA, IEC, UL
H x W x D 4.25 " x 4.00 " x 6.50 "
Gross Weight 2.9 lbs
Net Weight 2.9 lbs
