EHD3050VW
Eaton Circuit Breakers, F Series
Product images are for illustration purposes only. Please review specifications and documentation for exact product details.
EHD3050VW Eaton Circuit Breakers, F Series
CIRCUIT BREAKER
MFG Item Number
EATON-EHD3050VW
Item Number
EHD3050VW
Series
More specs
This item cannot be canceled or returned
Orders placed by 5:00pm Eastern time will ship today. If you would like to pick up your order, select Will Call during checkout if it is available.
Description
Circuit Breakers, F Series
Item #
EHD3050VW
CIRCUIT BREAKER
F Series Information
- HACR Rated
- 1, 2, 3, 4 Poles
- Suitable for Reverse Feed Use
Specifications
| Manufacturer Part Number | EATON-EHD3050VW |
|---|---|
| Manufacturer | Eaton |
| Product Series | F |
| Family Series | Eaton Circuit Breakers, F Series |
| Description | CIRCUIT BREAKER |
| Poles | 3 |
| Current Rating | 50 A |
| Max Voltage | 480 VAC |
| Trip Unit | Fixed Thermal / Fixed Magnetic |
| Neutral Pole | No |
| GFCI | No |
| Neutral Protection | No |
| 100% Rated | No |
| Auxiliary Switch | Optional |
| Shunt Trip | Optional |
| Undervoltage Release | Optional |
| Alarm Switch | Optional |
| UL Standard | 489 |
| Approvals | UL |
| Gross Weight | 4.5 lbs |
| Net Weight | 4.5 lbs |
