Specifications
| Country of Origin | United States |
|---|---|
| Manufacturer Part Number | EPBAD48 |
| Manufacturer | Marathon Special Products |
| Family Series | Marathon Special Products Power Distribution Blocks |
| Number of Poles | 1 |
| AC Voltage | 600 VAC |
| Current Rating | 200 A |
| Number of Inputs per Pole | 1 |
| Number of Outputs per Pole | 8 |
| Electrical Connection | Screw/Screw |
| Mounting | DIN Rail |
| Line Side Wire Range | 14-3/0 AWG; 6-3/0 AWG |
| Output Wire Range | 14-2 AWG; 6-2 AWG |
| Cover Included | No |
| Composition | Thermoplastic |
| Protection Rating | IP20 |
| Color | Gray |
| Approvals | CE, CSA, UL |
| H x W x D | 2.80 " x 1.20 " x 3.60 " |
| Net Weight | 0.305 lbs |
| Gross Weight | 0.31 lbs |
Description
Power Distribution Blocks, Series
Item #
EPBAD48
Distribution Block, 200A, 600V
Series Information
