Specifications
| Manufacturer Part Number | FAZ-C2/2 |
|---|---|
| Manufacturer | Eaton |
| Product Series | FAZ |
| Family Series | Eaton Circuit Breakers, FAZ Series |
| Poles | 2 |
| Current Rating | 2 A |
| Max Voltage | 480 VAC, 125 VDC |
| Trip Curve | C |
| Trip Unit | Fixed Thermal / Fixed Magnetic |
| Mounting | DIN Rail |
| Neutral Pole | No |
| Terminal Type | Screw |
| Auxiliary Switch | Optional |
| Shunt Trip | Optional |
| Undervoltage Release | Optional |
| Alarm Switch | Optional |
| UL Standard | 1077 |
| Approvals | CE, CSA, UL, VDE |
| H x W x D | 2.85 " x 1.45 " x 3.40 " |
| Net Weight | 0.495 lbs |
| Gross Weight | 0.53 lbs |
Description
Circuit Breakers, FAZ Series
Item #
FAZ-C2/2
Circuit Breaker, 2-P, 2A/480V, C,
FAZ Series Information
Documents & Resources Links
Videos
Alternatives
Compare available alternatives using the specifications that matter for this product.
| Image | Part | Description | Mounting | Series | Poles | Price | Action |
|---|---|---|---|---|---|---|---|
|
FAZ-C2/1-SP | Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker-supplementary protector,Single package,Medium levels of inrush current are expected,2 A,15 kAIC,Single-pole,277 V,5-10X/n,Q38,50-60 Hz,Standard terminals,C Curve | DIN Rail | FAZ | 1 |
Price unavailable
|
|
|
ST201M-C2 | ST201M-C2 Miniature Circuit Breaker ST201M-C2 Miniature Circuit Breaker C-Char., 10kA, 2A, 1P | DIN Rail | ST200M | 1 |
Price unavailable
|
|
|
ST202M-C2 | ST202M-C2 Miniature Circuit Breaker ST202M-C2 Miniature Circuit Breaker C-Char., 10kA, 2A, 2P | DIN Rail | ST200M | 2 |
Price unavailable
|
