Product images are for illustration purposes only. Please review specifications and documentation for exact product details.
Series
FAZ-K0.5/1 Eaton Circuit Breakers, FAZ Series
MFG #:
FAZ-K0.5/1
Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,0.5 A,15 kAIC,Single-pole,240/415 V,8-12X /n,Standard terminals,K curve
Specifications
| Manufacturer Part Number | FAZ-K0.5/1 |
|---|---|
| Manufacturer | Eaton |
| Product Series | FAZ |
| Family Series | Eaton Circuit Breakers, FAZ Series |
| Poles | 1 |
| Current Rating | 0.5 A |
| Max Voltage | 277 VAC, 48 VDC |
| Trip Curve | K |
| Trip Unit | Fixed Thermal / Fixed Magnetic |
| Mounting | DIN Rail |
| Neutral Pole | No |
| Terminal Type | Screw |
| Auxiliary Switch | Optional |
| Shunt Trip | Optional |
| Undervoltage Release | Optional |
| Alarm Switch | Optional |
| UL Standard | 1077 |
| Approvals | CE, CSA, UL, VDE |
| H x W x D | 2.36 " x 0.70 " x 3.15 " |
| Net Weight | 0.26 lbs |
| Gross Weight | 0.26 lbs |
Description
Circuit Breakers, FAZ Series
Item #
FAZ-K0.5/1
FAZ-K0,5/1 FAZ UL 1077 1P 0.5A K C
FAZ Series Information
Documents & Resources Links
Videos
Alternatives
Compare available alternatives using the specifications that matter for this product.
| Image | Part | Description | Mounting | Series | Poles | Price | Action |
|---|---|---|---|---|---|---|---|
|
S201P-K0.5 | Circuit Breaker, 1-P, 0.5A/277V, K, 480Y/277VAC, UL1077 Recognized, 10KAIC@277VAC, DIN Mount | DIN Rail | S200P | 1 |
Quote Required
|
|
|
ST201M-K0.5 | ST201M-K0,5 Miniature Circuit Breaker ST201M-K0,5 Miniature Circuit Breaker K-Char., 10kA, 0,5A, 1P | DIN Rail | ST200M | 1 |
Price unavailable
|
