Series
FAZ-K50/2 Eaton Circuit Breakers, FAZ Series
MFG #:
FAZ-K50/2
Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,50 A,15 kAIC,Two-pole,8-12X /n,Standard terminals,K curve
Specifications
| Country of Origin | Romania |
|---|---|
| Manufacturer Part Number | FAZ-K50/2 |
| Manufacturer | Eaton |
| Product Series | FAZ |
| Family Series | Eaton Circuit Breakers, FAZ Series |
| Poles | 2 |
| Current Rating | 50 A |
| Max Voltage | 480 VAC, 125 VDC |
| Trip Curve | K |
| Trip Unit | Fixed Thermal / Fixed Magnetic |
| Mounting | DIN Rail |
| Neutral Pole | No |
| Terminal Type | Screw |
| Auxiliary Switch | Optional |
| Shunt Trip | Optional |
| Undervoltage Release | Optional |
| Alarm Switch | Optional |
| UL Standard | 1077 |
| Approvals | CE, CSA, UL, VDE |
| H x W x D | 2.36 " x 1.39 " x 3.15 " |
| Net Weight | 0.53 lbs |
| Gross Weight | 0.53 lbs |
Description
Circuit Breakers, FAZ Series
Item #
FAZ-K50/2
FAZ UL 1077 2P 50A K CURVE
FAZ Series Information
Documents & Resources Links
Videos
Alternatives
Compare available alternatives using the specifications that matter for this product.
| Image | Part | Description | Mounting | Series | Poles | Price | Action |
|---|---|---|---|---|---|---|---|
|
ST202M-K50 | ST202M-K50 Miniature Circuit Breaker ST202M-K50 Miniature Circuit Breaker K-Char., 5kA, 50A, 2P | DIN Rail | ST200M | 2 |
Price unavailable
|
