FD32CPA2P
MFG #:
FD32CPA2P
Specifications
| Country of Origin | Mexico |
|---|---|
| Manufacturer Part Number | FD32CPA2P |
| Manufacturer | US Motors |
| Family Series | US Motors Motors |
| Type | Special Application Farm |
| Horsepower | 1-1/2 hp |
| Kilowatts | 1.1 kW |
| Speed | 1,725 RPM |
| RPM | 1,725 RPM |
| Number of Poles | 4 |
| Phase | 1 |
| Frequency | 60 Hz |
| NEMA Frame | 56 |
| AC Voltage | 115 VAC, 230 VAC |
| Nominal Voltage | 120 VAC, 240 VAC |
| Mounting | Rigid |
| Current Rating | 13.6 A |
| Overload Protection | Automatic |
| Net Weight | 39.8 lbs |
| Gross Weight | 39.8 lbs |
Description
Motors, Series
Item #
FD32CPA2P
Motor, 1.5 HP, 1800 RPM, 56
