Series

HFD3025 Eaton Circuit Breakers, C Series

MFG #:

EATON-6639C86G86

Eaton Series C complete molded case circuit breaker, F-frame, HFD, Complete breaker, Fixed thermal, Fixed magnetic trip type, Three-pole, 25 A, 600 Vac, 250 Vdc, Load side, 50/60 Hz

View Full Specs

Skip to the end of the images gallery

Product images are for illustration purposes only. Please review specifications and documentation for exact product details.

Skip to the beginning of the images gallery

Series

HFD3025 Eaton Circuit Breakers, C Series

Name: HFD3025 Eaton Circuit Breakers, C Series
Brand: Eaton
SKU: HFD3025-CHGP
Price: 2161.07 USD
Availability: BackOrder

MFG #:

EATON-6639C86G86

Item Number

HFD3025

Eaton Series C complete molded case circuit breaker, F-frame, HFD, Complete breaker, Fixed thermal, Fixed magnetic trip type, Three-pole, 25 A, 600 Vac, 250 Vdc, Load side, 50/60 Hz

View Full Specs

Request Lead Time

Qty

This item cannot be canceled or returned

Specifications

Specifications
Country of Origin	Dominican Republic
Manufacturer Part Number	EATON-6639C86G86
Manufacturer	Eaton
Product Series	C
Family Series	Eaton Circuit Breakers, C Series
Poles	3
Current Rating	25 A
Max Voltage	600 VAC, 250 VDC
Trip Unit	Fixed Thermal / Fixed Magnetic
Mounting	Panel
Approvals	UL
H x W x D	3.38 " x 4.13 " x 6.00 "
Gross Weight	4.35 lbs
Net Weight	4.35 lbs

Accessories

Compare compatible accessories for this product.

Accessories comparison
Part	Description	Series	Approvals	Price
3T100FB	Terminal Lug Kit, 3/PK, 100A Max, Steel, Standard Pressure Type Terminals, Accepts 14AWG-1/0 Cu/Al	Eaton Terminals	UL	Price unavailable
3TA225FD	Terminal Lug Kit, 3/Pk, 225A Max, Accepts 14AWG-4/0 WIRE	Eaton Terminals	UL	Price unavailable
HM1R06	Rotary Handle Kit, F Frame, N12, Includes Handle, 6in. Shaft and Operating Mechanism	Eaton Circuit Breakers		Price unavailable
HM1R12	Rotary Handle Kit, F Frame, N12, Includes Handle, 12in. Shaft and Operating Mechanism	Eaton Circuit Breakers		Price unavailable
HM1R16	Rotary Handle Kit, F Frame, N12, Includes Handle, 16in. Shaft and Operating Mechanism	Eaton Circuit Breakers		Price unavailable
