Specifications
| Country of Origin | Japan |
|---|---|
| Manufacturer Part Number | HW1B-M4F01-R |
| Manufacturer | IDEC |
| Product Series | NH-HMQ-H1 |
| Family Series | IDEC Switches, NH-HMQ-H1 Series |
| Illuminated | No |
| Operation | Momentary |
| Mounting | 22 mm |
| Operator Size (mm) | 40 mm |
| Contacts | 1NC |
| Max Voltage | 600 VAC, 600 VDC |
| Current Rating | 10 A |
| Bezel | Plastic Round |
| Lens/Button Shape | Mushroom |
| Operator Color | Red |
| Terminal Type | Fingersafe Screw |
| Protection Rating | IP65 |
| NEMA Rating | NEMA 1, NEMA 12, NEMA 13, NEMA 2, NEMA 3, NEMA 3R, NEMA 4, NEMA 4X, NEMA 5, NEMA 3S |
| Approvals | CE, CSA, UL |
| H x W x D | 1.63 " x 1.16 " x 2.89 " |
| Net Weight | 0.22 lbs |
| Gross Weight | 0.22 lbs |
Description
Switches, NH-HMQ-H1 Series
Item #
HW1B-M4F01-R
PUSHBUTTON, MOM, RED, 40mm MUSH, 1NC
NH-HMQ-H1 Series Information
- Choice of Plastic or Metallic Bezels
- IP20 or Spring Screw Terminals
- Flush, Extended or Mushroom
- Tamperproof Construction
- 22mm Mounting Size
- Easy to Assemble
