Product images are for illustration purposes only. Please review specifications and documentation for exact product details.
Series
HW2L-M1F11QD-R-120V IDEC Switches, HW Series
MFG #:
HW2L-M1F11QD-R-120V
PUSHBUTTON, MOM, RED, FLUSH, 120V DI FULL VOLTAGE, 22mm MOUNTING, LED 1NO&1NC CONTACT BLOCKS, SQUARE BEZEL
Specifications
| Country of Origin | Japan |
|---|---|
| Manufacturer Part Number | HW2L-M1F11QD-R-120V |
| Manufacturer | IDEC |
| Product Series | HW |
| Family Series | IDEC Switches, HW Series |
| Illuminated | Yes |
| Operation | Momentary |
| Mounting | 22 mm |
| Contacts | 1NO, 1NC |
| Max Voltage | 600 VAC, 600 VDC |
| Current Rating | 10 A |
| Bezel | Plastic Square |
| Lamp Type | LED |
| Nominal Lamp Voltage | 120 VAC |
| Lens/Button Shape | Square Flush |
| Operator Color | Red |
| Terminal Type | Fingersafe Screw |
| Protection Rating | IP65 |
| Approvals | CE, CSA, UL |
| H x W x D | 1.16 " x 1.63 " x 3.52 " |
| Net Weight | 0.1938 lbs |
| Gross Weight | 0.1938 lbs |
Description
Switches, HW Series
Item #
HW2L-M1F11QD-R-120V
PUSHBUTTON, MOM, RED, FLUSH, 120V DI
HW Series Information
- Choice of Plastic or Metallic Bezels
- IP20 or Spring Screw Terminals
- Incandescent or LED Types
- Tamperproof Construction
- 22mm Mounting Size
- Easy to Assemble
