Specifications
| Country of Origin | Japan |
|---|---|
| Manufacturer Part Number | HW4L-M4F02QD-W-12V |
| Manufacturer | IDEC |
| Product Series | HW |
| Family Series | IDEC Switches, HW Series |
| Illuminated | Yes |
| Operation | Momentary |
| Mounting | 22 mm |
| Contacts | 2NC |
| Max Voltage | 600 VAC, 600 VDC |
| Current Rating | 10 A |
| Bezel | Metal Round |
| Lamp Type | LED |
| Nominal Lamp Voltage | 12 VAC, 12 VDC |
| Lens/Button Shape | Mushroom |
| Operator Color | White |
| Protection Rating | IP65 |
| Approvals | CSA, UL |
| Net Weight | 0.2183 lbs |
| Gross Weight | 0.2183 lbs |
Description
Switches, HW Series
Item #
HW4L-M4F02QD-W-12V
Pushbutton, Mom, Wht, 40mm Mush, 12V
HW Series Information
- Choice of Plastic or Metallic Bezels
- IP20 or Spring Screw Terminals
- Incandescent or LED Types
- Tamperproof Construction
- 22mm Mounting Size
- Easy to Assemble
Documents & Resources Links
Videos
Added to Cart
HW4L-M4F02QD-W-12V IDEC Switches, HW Series, Pushbutton, Mom, Wht, 40mm Mush, 12V
Series HW
MFG #:
HW4L-M4F02QD-W-12V
Pushbutton, Mom, Wht, 40mm Mush, 12V Direct, 22mm Mounting, LED, 2NC Contact Blocks, Chrome Bezel
