Specifications
| Manufacturer Part Number | KDRMA7L1 |
|---|---|
| Manufacturer | TCI |
| Product Series | KDR |
| Family Series | TCI Line Reactors, KDR Series |
| Nominal Voltage | 480 V |
| Voltage | 480 V |
| Phase | 3 |
| Enclosed | No |
| Current Rating | 4.2 A |
| Inductance | 0.0065 H |
| Approvals | UL |
| H x W x D | 3.65 " x 1.90 " x 4.35 " |
| Net Weight | 1.695 lbs |
| Gross Weight | 1.83 lbs |
Description
Line Reactors, KDR Series
Item #
KDRMA7L1
Reactor, 480V, 4.2A, 3-PH, Open, 3pct.
KDR Series Information
- 3% & 5% Impedance units
- Harmonic Compensation ‑ Use on drive input or output
- Reduces Line notching
- Reduces Inverter Overcurrent and Overvoltage
- Improves True Power Factor
- UL Listed Available
