Specifications
| Manufacturer Part Number | L1410TM |
|---|---|
| Manufacturer | Baldor-ABB Motors |
| Product Series | L |
| Family Series | Baldor-ABB Motors Motors, L Series |
| Type | General Purpose |
| Horsepower | 5 hp |
| Speed | 1,800 RPM |
| RPM | 1,800 RPM |
| Phase | 1 |
| NEMA Frame | 184T |
| AC Voltage | 230 VAC |
| Nominal Voltage | 208 VAC, 240 VAC |
| Enclosure | Drip Proof |
| Mounting | Foot Mount, Rigid |
| Current Rating | 23 A |
| Inverter Duty | No |
| Composition | Steel |
| Bearing Type | Ball |
| Overload Protection | Manual |
| Length | 16.5 " |
| H x W x D | 13.25 " x 12.50 " x 23.00 " |
| Net Weight | 90 lbs |
| Gross Weight | 85 lbs |
Description
Motors, L Series
Item #
L1410TM
5HP, 1725RPM, 1PH, 60HZ, 184T, 3640LC
L Series Information
- Heavy Duty Base Seam Welded to the Frame
- Dynamically Balanced Rotors
- Heavy Gauge Steel Frame
- Ball Bearings
- 1/12 thru 15 Hp
Documents & Resources Links
Alternatives
Compare available alternatives using the specifications that matter for this product.
| Image | Part | Description | Voltage | Mounting | Series | Price | Action |
|---|---|---|---|---|---|---|---|
|
131622.00 | Motor, 5HP, /208-230V, 1740RPM DP Compressor Duty | 208 VAC, 240 VAC | Foot Mount, Rigid | General Purpose |
Price unavailable
|
Added to Cart
L1410TM Baldor-ABB Motors Motors, L Series, 5HP, 1725RPM, 1PH, 60HZ, 184T, 3640LC
Series L
MFG #:
L1410TM
5HP, 1725RPM, 1PH, 60HZ, 184T, 3640LC
Alternatives
131622.00 Leeson Motors, General Purpose Series
Series General Purpose
Series General Purpose
MFG #:
131622.00
Motor, 5HP, /208-230V, 1740RPM DP Compressor Duty
View More Details
