Name: ML30.106 Puls Power Supplies, Mini Line Series
Brand: Puls
SKU: ML30.106-PULS
Price: 202.05 USD
Availability: BackOrder

Specifications

Specifications
Country of Origin	China
Manufacturer Part Number	ML30.106
Manufacturer	Puls
Product Series	Mini Line
Family Series	Puls Power Supplies, Mini Line Series
Power	30 W
Nominal Input Voltage	120 VAC, 208 VAC, 240 VAC
AC Voltage	100-240 VAC
Input Frequency	47-63 Hz
Phase	1
Nominal Output Voltage	12 VDC
Output VDC	12-15 VDC
Output Current	1.4 A, 2.8 A
Number of Outputs	1
Mounting	DIN Rail
Enclosed	Yes
Encapsulated	No
Output Voltage Adj.	Yes
Overvoltage Protection	Yes
Overload Protection	Yes
Short Circuit Protection	Yes
Power Factor Correction	No
Parallel Operation	No
Remote Sensing	No
Remote On/Off Control	No
Operating Temperature	14-158 °F
Approvals	CE, cULus, cURus, UL508, UL60950
H x W x D	2.44 " x 5.51 " x 5.91 "
Net Weight	0.5313 lbs
Gross Weight	0.7275 lbs

Description

Power Supplies, Mini Line Series

Item #

ML30.106

Power Supply, 12VDC, 2.8A, 36W,

Mini Line Series Information

Single Output
5~56 VDC Outputs Available
Up to 7.5 Amp Output Available
85~550 VAC Inputs Available
CE, UL and C‑UL Approvals

Puls MiniLine power supplies are very compact, can be installed in seconds and are extremely reliable. PULS has reduced the number of critical components such as electrolytic capacitors and only uses the highest quality materials. The plastic housed MiniLine is available in a 25‑100 Watt range and with input voltages between 85‑550 VAC.

DIN Rail Mount
Wide DC Input Voltage
Rugged Plastic Housing
