Specifications
| Manufacturer Part Number | MS450-32 |
|---|---|
| Manufacturer | ABB |
| Product Series | MS |
| Family Series | ABB Manual Motor Protectors, MS Series |
| Current Rating | 50 A |
| FLA Adjustment Range | 22-32 |
| Phase | 1, 3 |
| Poles | 3 |
| Trip Class | Class 10 |
| Protection Rating | IP20 |
| Approvals | CE, CSA, UL |
| H x W x D | 5.79 " x 2.46 " x 6.50 " |
| Net Weight | 2.31 lbs |
| Gross Weight | 2.36 lbs |
Description
Manual Motor Protectors, MS Series
Item #
MS450-32
Manual Motor Protector, 22.0-32.0A
MS Series Information
- Rated up to 100 Amps
- Up to 40 HP @ 240V 3PH
- Up to 75 HP @ 480V 3PH
- UL, CSA, CE Approvals
- DIN Rail Mount
- IP20 Protection
- Wide Range of Accessories Available
