MSL2-120GR
Federal Signal Visual Signaling Devices, MSL Series
Product images are for illustration purposes only. Please review specifications and documentation for exact product details.
MSL2-120GR Federal Signal Visual Signaling Devices, MSL Series
MICROSTAT 2-HIGH 120VAC GREEN/RED
MFG Item Number
MSL2-120GR
Series
More specs
This item cannot be canceled or returned
Orders placed by 5:00pm Eastern time will ship today. If you would like to pick up your order, select Will Call during checkout if it is available.
Description
Visual Signaling Devices, MSL Series
Item #
MSL2-120GR
MICROSTAT 2-HIGH 120VAC GREEN/RED
MSL Series Information
- 24 VAC/VDC or 120 VAC/240 VAC
- PLC Compatible
- 4X Type Enclosure
- Pipe or Surface Mounted
- UL; cUL Approvals
The lenses lock together and snap apart with a simple twisting motion, allowing for easy lamp changes and quick lens resequencing. A rugged vibration‑resistant, thick‑filament wedge lamp fills each lens with light, providing excellent optical performance.
Wire connections are made through a 2‑piece terminal block. The MicroStat is designed to work with PLC outputs including "Triacs".
An optional 100,000‑hour LED light source is available in the five colors. This lamp, made of surface mounted LEDs, plugs directly into the same socket as the standard lamp.
An optional sound module can be installed in the top position of any MicroStat. The Sound Module Kit (MSS) consists of a slotted grille and board‑mounted piezoelectric horn. The sounder plugs directly into the wedge socket.
A pipe mount base, pipes and flashers are also available.
Specifications
| Country of Origin | United States |
|---|---|
| Manufacturer Part Number | MSL2-120GR |
| Manufacturer | Federal Signal |
| Product Series | MSL |
| Family Series | Federal Signal Visual Signaling Devices, MSL Series |
| Description | MicroStat Status Indicator, 2 High, 120VAC, Green/Red - Available in 24VAC/DC or 120VAC. Factory assembled. Small footprint – only 2.2 inch diameter 55.9 mm. Surface mount and integrated 3/4-inch NPT pipe mount. Five lens colors: Amber, Blue, Clear, |
| Number of Tiers | 2 |
| Voltage | 120 VAC |
| Nominal Voltage | 120 VAC |
| Function | Non-Flashing |
| Lamp Type | Incandescent |
| Audible Alarm | None |
| Stack Configuration | Green, Red |
| Mounting | Pipe, Surface |
| Approvals | cUL, UL |
| H x W x D | 2.50 " x 4.50 " x 13.00 " |
| Net Weight | 0.85 lbs |
| Gross Weight | 0.85 lbs |
