NZMH3-AEF300-NA
Eaton Circuit Breakers, NZM3 Series
Product images are for illustration purposes only. Please review specifications and documentation for exact product details.
NZMH3-AEF300-NA Eaton Circuit Breakers, NZM3 Series
UL/CSA/IEC ELEC TRIP MCCB 300A 3P
MFG Item Number
EATON-269284
Item Number
NZMH3-AEF300-NA
Series
More specs
This item cannot be canceled or returned
Orders placed by 5:00pm Eastern time will ship today. If you would like to pick up your order, select Will Call during checkout if it is available.
Description
Circuit Breakers, NZM3 Series
Item #
NZMH3-AEF300-NA
UL/CSA/IEC ELEC TRIP MCCB 300A 3P
NZM3 Series Information
- Panel Mount
- 250 ~ 630 Amps
- 3/4 Poles
- IEC 60947‑2
- 690 VAC
Specifications
| Manufacturer Part Number | EATON-269284 |
|---|---|
| Manufacturer | Eaton |
| Product Series | NZM3 |
| Family Series | Eaton Circuit Breakers, NZM3 Series |
| Description | UL/CSA/IEC ELEC TRIP MCCB 300A 3P FIXED THERM SET SCREW |
| Poles | 3 |
| Current Rating | 300 A |
| Max Voltage | 690 VAC |
| Trip Unit | Electronic |
| Mounting | Panel |
| Terminal Type | Screw |
| Auxiliary Switch | Optional |
| Shunt Trip | Optional |
| Undervoltage Release | Optional |
| UL Standard | 489 |
| Approvals | CCC, CE, CSA, UL |
| H x W x D | 6.50 " x 5.50 " x 11.70 " |
| Gross Weight | 5.5 lbs |
| Net Weight | 5.5 lbs |
