Product images are for illustration purposes only. Please review specifications and documentation for exact product details.
Series
PKZM0-0.25 Eaton Manual Motor Protectors, PKZM0 Series
MFG #:
PKZM0-0.25
Eaton IEC motor control FVNR Manual Motor Controller, 6.3A, 45 mm Frame size, 110V 50 Hz, 120V 60 Hz coil,
Specifications
| Country of Origin | Germany |
|---|---|
| Manufacturer Part Number | PKZM0-0.25 |
| Manufacturer | Eaton |
| Product Series | PKZM0 |
| Family Series | Eaton Manual Motor Protectors, PKZM0 Series |
| Current Rating | 0.25 A |
| FLA Adjustment Range | 0.16-0.25 |
| Phase | 3 |
| Poles | 3 |
| Approvals | CSA, UL |
| H x W x D | 3.00 " x 1.80 " x 3.70 " |
| Net Weight | 0 lbs |
| Gross Weight | 0.57 lbs |
Description
Manual Motor Protectors, PKZM0 Series
Item #
PKZM0-0.25
PKZM0-0,25 MANUAL MOTOR ctlLER-0.16-0.2
PKZM0 Series Information
- Screw Terminal Connection
- Up to 32A
- UL Listed CSA Certified
Documents & Resources Links
Videos
Alternatives
Compare available alternatives using the specifications that matter for this product.
| Image | Part | Description | Series | Current Rating | Price | Action |
|---|---|---|---|---|---|---|
|
XTPRP25BC1 | Eaton IEC motor control Manual Motor Protector, 0.25A, 45 mm Frame size, Class 10 trip type, Rotary type | XTMMP | 0.25 A |
Price unavailable
|
