Specifications
| Manufacturer Part Number | EATON-072734 |
|---|---|
| Manufacturer | Eaton |
| Product Series | PKZM0 |
| Family Series | Eaton Manual Motor Protectors, PKZM0 Series |
| Current Rating | 1 A |
| FLA Adjustment Range | 0.63-1 |
| Phase | 3 |
| Poles | 3 |
| Approvals | CSA, UL |
| H x W x D | 3.00 " x 1.80 " x 3.70 " |
| Net Weight | 0.5 lbs |
| Gross Weight | 0.58 lbs |
Description
Manual Motor Protectors, PKZM0 Series
Item #
PKZM0-1
Manual Motor Starter, 0.63-1A Range
PKZM0 Series Information
The proven PKZM0 switches motors from 0.16 to 32 A. The short‑circuit breaking capacity is now rated to 150 kA up to 12 A and 50 kA up to 32 A. The PKZM 4 also has a breaking capacity up to 50 kA. With this, current limiters become almost unnecessary. These motor‑protective circuit‑breakers are matched to the DIL contactor series, which is ideal for the configuration of motor‑starter combinations.
Documents & Resources Links
Alternatives
Compare available alternatives using the specifications that matter for this product.
| Image | Part | Description | Series | Current Rating | Price | Action |
|---|---|---|---|---|---|---|
|
XTPR001BC1 | Eaton IEC motor control Manual Motor Protector, 1A, 45 mm Frame size, Class 10 trip type, Rotary type | XTMMP | 1 A |
Price unavailable
|
