Specifications
Country of Origin	Taiwan
Manufacturer Part Number	PS5R-VC12
Manufacturer	IDEC
Product Series	PS5R-V
Family Series	IDEC Power Supplies, PS5R-V Series
Power	30 W
Nominal Input Voltage	120 VAC, 240 VAC
AC Voltage	100-240 VAC
Input Frequency	60 Hz
Phase	1
Nominal Output Voltage	12 VDC
Output VDC	12 VDC
Output Current	2.5 A
Number of Outputs	1
Mounting	DIN Rail, Panel
Enclosed	Yes
Encapsulated	No
Output Voltage Adj.	Yes
Overvoltage Protection	Yes
Overload Protection	Yes
Short Circuit Protection	Yes
Power Factor Correction	No
Parallel Operation	No
Remote Sensing	No
Remote On/Off Control	No
Operating Temperature	-13-158 °F
Approvals	CE, cULus, TUV, UL1310 CLASS 2, UL508
H x W x D	1.48 " x 4.07 " x 5.55 "
Net Weight	0.451 lbs
Gross Weight	0.451 lbs

Alternatives

Compare available alternatives using the specifications that matter for this product.

Alternatives comparison
Image	Part	Description	Voltage	Mounting	Series	Price	Action
	1SVR427032R1000	The CP-E 12/2.5 is a power supply from the CP-E range. The primary switch mode power supply offers a wide range input of 85-264 V AC and 90-375 V DC, rated input voltage is 100-240 V AC. The rated output power is 30 W, rated output current is 2.5 A	100-240 VAC	DIN Rail	CP	Price unavailable

Accessories

Compare compatible accessories for this product.

Accessories comparison
Image	Part	Description	Series	SKU	Price	Action
	PS9Z-5R2B	Panel Mount Bracket for PS5R-S	IDEC Power Supplies	PS9Z-5R2B-IDEC	Price unavailable
