main product photo

Product images are for illustration purposes only. Please review specifications and documentation for exact product details.

Eaton
Series
PSG

PSG240F24RM Eaton Power Supplies, PSG Series

MFG #:
PSG240F24RM
Power Supply
View Full Specs

Request Lead Time
This item cannot be canceled or returned

Specifications

Specifications
Manufacturer Part Number PSG240F24RM
Manufacturer Eaton
Product Series PSG
Family Series Eaton Power Supplies, PSG Series
Power 240 W
Nominal Input Voltage 480 VAC, 575 VAC
AC Voltage 320-600 VAC
Input Frequency 47-63 Hz
Phase 3
Nominal Output Voltage 24 VDC
Output VDC 24-28 VDC
Output Current 10 A
Number of Outputs 1
Mounting DIN Rail
Enclosed Yes
Encapsulated No
Output Voltage Adj. Yes
Overvoltage Protection Yes
Overload Protection Yes
Short Circuit Protection No
Power Factor Correction No
Parallel Operation Yes
Remote Sensing No
Remote On/Off Control No
Operating Temperature -13-176 °F
Approvals CE, CSA, UL
Comments 450~800 VDC Input
H x W x D 4.62 " x 2.76 " x 4.76 "
Net Weight 2.25 lbs
Gross Weight 2.28 lbs
