RH2B-UL-AC240
IDEC Relays, RH Series
Product images are for illustration purposes only. Please review specifications and documentation for exact product details.
RH2B-UL-AC240 IDEC Relays, RH Series
Relay, DPDT, 10A, 240VAC w/Ind Light
MFG Item Number
RH2B-UL-AC220-240
Item Number
RH2B-UL-AC240
Series
More specs
This item cannot be canceled or returned
Orders placed by 5:00pm Eastern time will ship today. If you would like to pick up your order, select Will Call during checkout if it is available.
Description
Relays, RH Series
Item #
RH2B-UL-AC240
Relay, DPDT, 10A, 240VAC w/Ind Light
RH Series Information
- AC and DC Coils
- 10 Amp Contacts
- Four Contact Arrangements
- UL Recognized E66043/E55996
- Plug In or PC Mount
- Industry Standard Package
- .187" Quick Connect Terminals
- Flange Mount Available
- Common Options Include Check Button and Indicator Light
Specifications
| Manufacturer Part Number | RH2B-UL-AC220-240 |
|---|---|
| Manufacturer | IDEC |
| Product Series | RH |
| Family Series | IDEC Relays, RH Series |
| Description | Relay, DPDT, 10A, 240VAC w/Ind Light |
| Coil Voltage | 240 VAC |
| Contacts | DPDT |
| Mounting | Plug In |
| Termination | .187 " Flat Blade |
| Enclosure | Plastic |
| Number of Connections | 8 |
| Status Indicator | Yes |
| Push-to-Test | No |
| Diode | No |
| Material | Silver Cadmium Oxide |
| Nominal Coil Voltage | 240 VAC |
| Current Rating | 10 A |
| Bifurcated Contact | No |
| Mechanical Latch | No |
| Safety Guided | No |
| H x W x D | 1.08 " x 0.83 " x 1.65 " |
| Net Weight | 0.0819 lbs |
| Gross Weight | 0.0819 lbs |
