Specifications
| Country of Origin | Japan |
|---|---|
| Manufacturer Part Number | RU2S-C-A24 |
| Manufacturer | IDEC |
| Product Series | RU |
| Family Series | IDEC Relays, RU Series |
| Coil Voltage | 24 VAC |
| Contacts | DPDT |
| Mounting | Plug In |
| Termination | .110 " Flat Blade |
| Enclosure | Plastic |
| Number of Connections | 8 |
| Status Indicator | Yes |
| Push-to-Test | Yes |
| Diode | No |
| Material | Silver Tin Oxide Indium |
| Nominal Coil Voltage | 24 VAC |
| Current Rating | 10 A |
| Bifurcated Contact | No |
| Mechanical Latch | No |
| Safety Guided | No |
| H x W x D | 1.05 " x 0.80 " x 1.55 " |
| Net Weight | 0.115 lbs |
| Gross Weight | 0.115 lbs |
Description
Relays, RU Series
Item #
RU2S-C-A24
RELAY, DPDT, 10A, 24VAC COIL
RU Series Information
- AC and DC Coils
- 10/6/3 Amp Std/Bifur Contacts
- Two Contact Arrangements
- UL Recognized E66043
- Plug In
- RoHS Compliant
- Non Polarized LED Indicator Included
- Solder Free Construction
- Mechanical Flag Indicator Standard
- Snap On Marking Plate Standard
- Color Coded Coils
- Manual Latching Lever Standard
- Optional Diode Across DC Coils Available
- Momentary Check Button Available
