Product images are for illustration purposes only. Please review specifications and documentation for exact product details.
Series
T-2-53518-3S Acme Electric Transformers, T Series
MFG #:
T2535183S
Item Number
T-2-53518-3S
Low Voltage Distribution Transformer - Single Phase, 240X480 - 120/240V, 25kVA
Specifications
| Manufacturer Part Number | T2535183S |
|---|---|
| Manufacturer | Acme Electric |
| Product Series | T |
| Family Series | Acme Electric Transformers, T Series |
| Phase | 1 |
| Type | Distribution |
| VA Rating | 25,000 VA |
| Primary Voltage | 240 V, 480 V |
| Secondary Voltage | 120 V, 240 V |
| Enclosed | Yes |
| Primary Fuseholder | Not Available |
| Secondary Fuseholder | Not Available |
| Mounting | Wall |
| NEMA Rating | NEMA 3R |
| Insulation Class | Class H |
| Temperature Rise (F) | 239 °F |
| Approvals | CSA, UL |
| H x W x D | 13.34 " x 16.13 " x 18.44 " |
| Net Weight | 250 lbs |
| Gross Weight | 250 lbs |
Description
Transformers, T Series
Item #
T-2-53518-3S
TFMR 1PH 25KVA 240X480-120/240
T Series Information
- General Purpose Transformer‑Dry Type
- UL Listed
- 1 Phase, 3 Phase
- Housed in NEMA 3R Enclosures
- Resin Encapsulation Keeps Out Moisture and Dirt
Documents & Resources Links
Videos
Alternatives
Compare available alternatives using the specifications that matter for this product.
| Image | Part | Description | Mounting | Series | Phase | Price | Action |
|---|---|---|---|---|---|---|---|
|
Q025LEKF | HPS Titan, 25kVA, 1PH, NEMA 3R, Pri 240x480, Sec 120/240, 14.5in.Hx21.38in.Wx10.75in.D | Wall | HPS Titan | 1 |
Price unavailable
|
