T14S3DCR
MFG #:
T14S3DCR
Specifications
| Country of Origin | Mexico |
|---|---|
| Manufacturer Part Number | T14S3DCR |
| Manufacturer | US Motors |
| Family Series | US Motors Motors |
| Type | General Purpose |
| Horsepower | 1/4 hp |
| Kilowatts | 0.2 kW |
| Speed | 1,140 RPM |
| RPM | 1,140 RPM |
| Number of Poles | 6 |
| Phase | 3 |
| Frequency | 60 Hz |
| NEMA Frame | 56C |
| AC Voltage | 208-230 VAC, 460 VAC |
| Nominal Voltage | 208 VAC, 240 VAC, 480 VAC |
| Enclosure | Totally Enclosed Fan Cooled |
| Mounting | C-Face |
| Current Rating | 1.4-1.4 A, 0.7 A |
| Composition | Rolled Steel |
| Bearing Type | Ball |
| Overload Protection | None |
| H x W x D | 10.88 " x 10.50 " x 15.32 " |
| Net Weight | 27 lbs |
| Gross Weight | 27 lbs |
Description
Motors, Series
Item #
T14S3DCR
Motor, 1/4 HP, 1200 RPM, 56C
