TR-51628-16 Macromatic Relays, TR-5 Series
MFG #:
TR-51628-16
TIME DELAY RELAY; 24VAC/DC OFF DELAY; 0.6-60 MIN
View Full Specs
main product photo

Product images are for illustration purposes only. Please review specifications and documentation for exact product details.

Macromatic
Series
TR-5

TR-51628-16 Macromatic Relays, TR-5 Series

MFG #:
TR-51628-16
TIME DELAY RELAY; 24VAC/DC OFF DELAY; 0.6-60 MIN
View Full Specs

Request Lead Time
This item cannot be canceled or returned

Specifications

Specifications
Manufacturer Part Number TR-51628-16
Manufacturer Macromatic
Product Series TR-5
Family Series Macromatic Relays, TR-5 Series
Operation Off Delay
Contacts DPDT
Mounting Socket
Time Range Adjustment Onboard
Adjustment Operator Knob
Timing Range 0.6-60 Min
Max Time 60 Min
Nominal Coil Voltage 24 VAC, 24 VDC
AC Voltage 24 VAC
DC Voltage 24 VDC
Contact Rating 10 A
Termination 11 Pin
Approvals CE, CSA, cULus
H x W x D 2.30 " x 1.75 " x 3.85 "
Net Weight 0.24 lbs
Gross Weight 0.275 lbs
