U12S3ACR
MFG #:
U12S3ACR
Specifications
| Country of Origin | Mexico |
|---|---|
| Manufacturer Part Number | U12S3ACR |
| Manufacturer | US Motors |
| Family Series | US Motors Motors |
| Type | General Purpose |
| Horsepower | 1/2 hp |
| Kilowatts | 0.4 kW |
| Speed | 1,155 RPM |
| RPM | 1,155 RPM |
| Number of Poles | 6 |
| Phase | 3 |
| Frequency | 60 Hz |
| NEMA Frame | 56C |
| AC Voltage | 208-230 VAC, 460 VAC |
| Nominal Voltage | 208 VAC, 240 VAC, 480 VAC |
| Enclosure | Totally Enclosed Fan Cooled |
| Mounting | C-Face Footless |
| Current Rating | 2.1-2.1 A, 1 A |
| Composition | Rolled Steel |
| H x W x D | 15.50 " x 12.50 " x 19.50 " |
| Net Weight | 25 lbs |
| Gross Weight | 25 lbs |
Description
Motors, Series
Item #
U12S3ACR
Motor, 1/2 HP, 1200 RPM, 56C
