Specifications
Manufacturer Part Number	VWDM3542
Manufacturer	Baldor-ABB Motors
Family Series	Baldor-ABB Motors Motors
Type	Washdown
Horsepower	3/4 hp
Speed	1,750 RPM
RPM	1,750 RPM
Phase	3
Frequency	60 Hz
NEMA Frame	56C
AC Voltage	230 VAC
Nominal Voltage	208 VAC, 240 VAC
Enclosure	Totally Enclosed Non-Ventilated
Mounting	Footless
Current Rating	2.4 A
Service Factor	1.25
Composition	Steel
H x W x D	11.38 " x 11.75 " x 16.50 "
Net Weight	29 lbs
Gross Weight	33 lbs

Alternatives

Compare available alternatives using the specifications that matter for this product.

Alternatives comparison
Image	Part	Description	Voltage	Mounting	Series	Price	Action
	113019.00	Motor, 0.75HP, 208-230/460V, 1725RPM TENV Washguard	208 VAC, 240 VAC, 480 VAC	C-Face Less Base	Washguard	Price unavailable
