WDP1P2AHC
MFG #:
WDP1P2AHC
Specifications
| Country of Origin | Mexico |
|---|---|
| Manufacturer Part Number | WDP1P2AHC |
| Manufacturer | US Motors |
| Family Series | US Motors Motors |
| Type | Special Application Washdown |
| Horsepower | 1 hp |
| Kilowatts | 0.8 kW |
| Speed | 1,725 RPM |
| RPM | 1,725 RPM |
| Number of Poles | 4 |
| Phase | 3 |
| Frequency | 60 Hz |
| NEMA Frame | 56HC |
| AC Voltage | 208-230 VAC, 460 VAC, 190 VAC, 380 VAC |
| Nominal Voltage | 208 VAC, 240 VAC, 380 VAC, 480 VAC |
| Enclosure | Totally Enclosed Fan Cooled |
| Mounting | C-Face Footed |
| Current Rating | 3.5-3.4 A, 1.7 A |
| Overload Protection | None |
| H x W x D | 12.00 " x 12.00 " x 18.50 " |
| Net Weight | 31 lbs |
| Gross Weight | 31 lbs |
Description
Motors, Series
Item #
WDP1P2AHC
Motor, 1 HP, 1800 RPM, 56HC
