Specifications
| Country of Origin | Germany |
|---|---|
| Manufacturer Part Number | XTSC020BCBD |
| Manufacturer | Eaton |
| Product Series | XTSC |
| Family Series | Eaton Manual Motor Controllers, XTSC Series |
| Current Rating | 20 A |
| FLA Adjustment Range | 16-20 |
| Voltage | 220 VDC |
| Reversing | No |
| Frame Size-MMP | B |
| Frame Size-Contactor | C |
| Approvals | CE, UL |
| H x W x D | 4.89 " x 1.78 " x 9.28 " |
| Net Weight | 0.001 lbs |
| Gross Weight | 0.001 lbs |
Description
Manual Motor Controllers, XTSC Series
Item #
XTSC020BCBD
MMC FVNR 16-20A B-MMP C-CONT 1NO
XTSC Series Information
- Visible Trip Indication
- Test Trip Function
- Class 10 Overload Protection
- Built‑in Heater and Magnetic Trip Elements to Protect the Motor
- Control Inputs Located at Front of Starter for Easy Access and Wiring
- Wide Range of Coils
- Adjustment Dial for Setting Motor FLA
- 1NO‑1NC Auxiliary Contact as Standard on Manual Motor Controller and Combination Motor Controller
Documents & Resources Links
Videos
Added to Cart
XTSC020BCBD Eaton Manual Motor Controllers, XTSC Series, MMC FVNR 16-20A B-MMP C-CONT 1NO
Series XTSC
MFG #:
XTSC020BCBD
Eaton XT IEC FVNR Manual Motor Controller, 25A, 55 mm Frame size, 220 Vdc coil,220 Vdc
