Specifications

Specifications
Manufacturer Part Number	Y544
Manufacturer	Marathon Electric
Product Series	General Purpose
Family Series	Marathon Electric Motors, GENERAL PURPOSE Series
Type	Inverter Rated
Horsepower	5 hp
Speed	1,200 RPM
RPM	1,200 RPM
Phase	3
NEMA Frame	215TC
AC Voltage	230 VAC, 460 VAC
Nominal Voltage	208 VAC, 240 VAC, 415 VAC, 480 VAC
Enclosure	Totally Enclosed Non-Ventilated
Mounting	C-Face Footed
Current Rating	15.4 A
Inverter Duty	Yes
Composition	Aluminum
Bearing Type	Ball
Overload Protection	Thermostat
Length	20.54 "
Approvals	CE, CSA, UL
Net Weight	146 lbs
Gross Weight	146 lbs

Description

Motors, General Purpose Series

Item #

Y544

MOTOR, AC, 5HP, 1200RPM, 230/460V

General Purpose Series Information

1/8~350 Horsepower
230, 230/460 or 575 VAC
NEMA Frames 56~449
Various Enclosure Types
C‑Face/Rigid Mounting

Marathon High Performance Inverter Duty motors include the microMAX, Black Max, and Blue Max series. These motors are specifically designed for applications in which a high constant torque speed range is required. Typical uses include: machine tools, conveyors, packing machines, batching machines, printing equipment, metal processing, crane and hoist, pumps, compressors, and textile processing.

UL, CSA and CE Approvals
Continuous Duty at 104 Degrees F Ambient

Documents & Resources

Documents & Resources Links

Videos

Alternatives

Compare available alternatives using the specifications that matter for this product.

Alternatives comparison
Image	Part	Description	Voltage	Mounting	Series	Price	Action
	IDM3768T	5HP, 1160RPM, 3PH, 60HZ, 215TC, 0740M, TEBC, F1	208 VAC, 240 VAC	Foot Mount	Baldor-ABB Motors Motors	Price unavailable
