YR40.241 Puls Power Supplies, Dimension Series
Redundancy Module, 24-28VDC, 40A,
MFG Item Number
YR40.241
Series
More specs
This item cannot be canceled or returned
Orders placed by 5:00pm Eastern time will ship today. If you would like to pick up your order, select Will Call during checkout if it is available.
Description
Power Supplies, Dimension Series
Item #
YR40.241
Redundancy Module, 24-28VDC, 40A,
Dimension Series Information
- Single Output
- 12~72 VDC Outputs Available
- Up tp 40 Amp Outputs Available
- 100~552 VAC Inputs Available
- CE, UL and C‑UL Approvals
- DIN Rail Mount
- High Efficiency ‑ Up to 96%
- Single or Three Phase Units
Specifications
| Country of Origin | Czech Republic |
|---|---|
| Manufacturer Part Number | YR40.241 |
| Manufacturer | Puls |
| Product Series | Dimension |
| Family Series | Puls Power Supplies, Dimension Series |
| Description | Redundancy Module, 24-28VDC, 40A, Dual Input |
| Number of Inputs | 2 |
| Nominal Input Voltage | 12 V, 24 V |
| Input Voltage | 8-36 VDC |
| Max Output Current | 40 A |
| Mounting | DIN Rail |
| Terminal Type | Spring Clamp |
| Approvals | cUL, cURus, CSA, CE, GL |
| H x W x D | 2.09 " x 5.91 " x 7.20 " |
| Net Weight | 0.75 lbs |
| Gross Weight | 1.1376 lbs |
