Specifications
| Manufacturer Part Number | 113901.00 |
|---|---|
| Manufacturer | Leeson |
| Product Series | Special Voltage |
| Family Series | Leeson Motors, Special Voltage Series |
| Type | General Purpose |
| Horsepower | 1/2 hp |
| Speed | 3,000 RPM |
| RPM | 3,000 RPM |
| Number of Poles | 2 |
| Phase | 1 |
| NEMA Frame | 56 |
| Nominal Voltage | 120 VAC, 240 VAC |
| Enclosure | Drip Proof |
| Mounting | Foot Mount, Rigid |
| Current Rating | 3.8 A |
| Service Factor | 1.25 |
| Composition | Steel |
| Bearing Type | Ball |
| Length | 10.34 " |
| Approvals | CSA, UL |
| Net Weight | 0 lbs |
| Gross Weight | 0 lbs |
Description
Motors, Special Voltage Series
Item #
113901.00
Motor, 0.5HP, 110/220V, 2850RPM
Special Voltage Series Information
- Standard, EPACT and Premium efficient ratings
- Inverter rated
- Class B insulation systems ‑ 42, 48 and 56 frames
- Class F insulation system ‑ 140 frame and higher
- Shielded ball bearings for direct coupled applications.
Applications: For use where special voltages are required. Ideally suited for use on pumps, compressors, fans, blowers, conveyors, machine tools and other industrial applications
- Rolled steel, aluminum, and cast iron frame material designs
- Continuous duty
- Dynamically balanced rotors
- Torques exceed NEMA performance standards
- UL recognized and CSA certified
