Specifications
| Manufacturer Part Number | L1208-50 |
|---|---|
| Manufacturer | Baldor-ABB Motors |
| Product Series | L |
| Family Series | Baldor-ABB Motors Motors, L Series |
| Type | General Purpose |
| Horsepower | 1/2 hp |
| Speed | 3,600 RPM |
| RPM | 3,600 RPM |
| Phase | 1 |
| NEMA Frame | 48 |
| AC Voltage | 115 VAC, 230 VAC |
| Nominal Voltage | 120 VAC, 208 VAC, 240 VAC |
| Enclosure | Drip Proof |
| Mounting | Foot Mount, Rigid |
| Current Rating | 3.7 A |
| Inverter Duty | No |
| Composition | Steel |
| Bearing Type | Ball |
| Overload Protection | None |
| Length | 9.13 " |
| Comments | Wound for 50 Hertz Service |
| H x W x D | 10.00 " x 11.13 " x 14.00 " |
| Net Weight | 26 lbs |
| Gross Weight | 25 lbs |
Description
Motors, L Series
Item #
L1208-50
.5 /KW .37, 2870RPM, 1PH, 50HZ, 48
L Series Information
- Heavy Duty Base Seam Welded to the Frame
- Dynamically Balanced Rotors
- Heavy Gauge Steel Frame
- Ball Bearings
- 1/12 thru 15 Hp
Documents & Resources Links
Alternatives
Compare available alternatives using the specifications that matter for this product.
| Image | Part | Description | Voltage | Mounting | Series | Price | Action |
|---|---|---|---|---|---|---|---|
|
113901.00 | Motor, 0.5HP, 110/220V, 2850RPM IP22 General Purpose - 50Hz | 120 VAC, 240 VAC | Foot Mount, Rigid | Special Voltage |
Quote Required
|
Added to Cart
L1208-50 Baldor-ABB Motors Motors, L Series, .5 /KW .37, 2870RPM, 1PH, 50HZ, 48
Series L
MFG #:
L1208-50
.5 /KW .37, 2870RPM, 1PH, 50HZ, 48
Alternatives
113901.00 Leeson Motors, Special Voltage Series
Series Special Voltage
Series Special Voltage
MFG #:
113901.00
Motor, 0.5HP, 110/220V, 2850RPM IP22 General Purpose - 50Hz
View More Details
