Specifications
| Manufacturer Part Number | CWM40-00-20V24 |
|---|---|
| Manufacturer | WEG Electric |
| Product Series | CWM |
| Family Series | WEG Electric Contactors, CWM Series |
| Type | AC Non-Reversing IEC |
| Nominal Coil Voltage | 208 VAC, 240 VAC |
| Coil Voltage | 208-240 VAC |
| Coil Type | Magnetic |
| Poles | 2NO |
| Frame Size | CWM40 |
| Auxiliary Contact | None |
| Termination | Screw |
| Overload Relays | RW27-1D3, RW67-1D3 |
| General Purpose (AC1) | 60 A |
| UL Motor Switching (AC3) | 40 A |
| H x W x D | 3.55 " x 2.15 " x 4.00 " |
| Net Weight | 1.32 lbs |
| Gross Weight | 1.32 lbs |
Description
WEG CWM Series 40A Two-Pole Compact Contactor, 208-240VAC Coil
The WEG CWM40-00-20V24 is a compact, 40-amp two-pole power contactor designed for switching resistive and capacitive loads in industrial and commercial control systems. Featuring a 208-240VAC coil (180-208V at 50 Hz / 208-240V at 60 Hz), it is well-matched for single-phase or DC bus switching applications including lighting, heating, capacitor bank switching, and other non-motor loads. The two-pole (2NO) main contact configuration handles high-current switching without auxiliary contacts in this base configuration, keeping the package compact and cost-effective. Built to IEC 60947-4-1 standards, the CWM series features screw-clamp terminals for secure wiring, a low-profile footprint for space-constrained panel installations, and a modular design that accepts auxiliary contact blocks for expanded functionality. Suitable for HVAC systems, power factor correction panels, and general industrial switching.
Contactors, CWM Series
Item #
CWM40-00-20V24
Contactor, 2-P N/O, 208-240VAC, 40A
CWM Series Information
- 24~600 VAC/VDC Coils
- Up to 300 HP @ 240V
- Up to 600 HP @ 460V
- UL, IEC, CE Approved
- Up to 800 Amps
- IP20 Finger Protection
- CSA Certified
Documents & Resources Links
Videos
Accessories
Compare compatible accessories for this product.
| Image | Part | Description | Series | Type | Price | Action |
|---|---|---|---|---|---|---|
|
|
BCA4-40V24 | Coil 4 Term. 208-240V | Coil |
Price unavailable
|
||
|
BCXMF01 | Auxiliary Contact Block, 1NC, Front | Auxiliary Contact |
Price unavailable
|
||
|
BCXMF10 | Auxiliary Contact Block, 1NO, Front/ Top Mount | Auxiliary Contact |
Price unavailable
|
||
|
BCXMFA10 | Auxiliary Contact Block, 1NO, Front | Auxiliary Contact |
Price unavailable
|
||
|
BCXMFR01 | Auxiliary Contact Block, 1NC, Front | Auxiliary Contact |
Price unavailable
|
||
|
BCXML11 | Auxiliary Contact Block, 1NO/1NC, Side Mount, Mounts to Contactor | Auxiliary Contact |
Price unavailable
|
||
|
BCXML20 | Auxiliary Contact Block, 2NO, Side Mount | Auxiliary Contact |
Price unavailable
|
||
|
BCXMRL11 | Auxiliary Contact Block, 1NO/1NC, Side Mount, Mounts to Existing Aux Block-Does not Mnt to Contactot | Auxiliary Contact |
Price unavailable
|
||
|
BCXMRL20 | Auxiliary Contact Block, 2NO, Side | Auxiliary Contact |
Price unavailable
|
||
|
RW27-1D2-D018 | 2 POLE OLR CLS10 Rang 1.2-1.8A | Bimetallic |
Price unavailable
|
||
|
RW27-1D2-D028 | Overload, 2 Pole Olr Cls10 Rang | RW | Bimetallic |
Price unavailable
|
|
|
RW27-1D2-D063 | Overload, 2 Pole Olr Cls10 Rang | RW | Bimetallic |
Price unavailable
|
|
|
RW27-1D2-D125 | Overload, 2 Pole Olr Cls10 Rang | RW | Bimetallic |
Price unavailable
|
|
|
RW27-1D2-U004 | Overload, 2 Pole Olr Cls10 Rang | RW | Bimetallic |
Price unavailable
|
|
|
RW27-1D2-U008 | Overload, 2 Pole Olr Cls10 Rang | RW | Bimetallic |
Price unavailable
|
|
|
RW27-1D2-U010 | 2 POLE OLR CLS10 Rang 7.0-10A | Bimetallic |
Price unavailable
|
||
|
RW27-1D2-U015 | Overload, 2 Pole Olr Class10 Rang | RW | Bimetallic |
Price unavailable
|
|
|
RW27-1D2-U017 | Overload, 2 Pole Olr Class10 Rang | RW | Bimetallic |
Price unavailable
|
|
|
RW27-1D2-U023 | Overload, 2 Pole Olr Class10 Rang | RW | Bimetallic |
Price unavailable
|
|
|
RW27-1D2-U032 | Overload, 2 Pole Olr Class10 Rang | RW | Bimetallic |
Price unavailable
|
|
|
RW67-1D2-U040 | Overload, 2 Pole Olr Class10 Rang | RW | Bimetallic |
Price unavailable
|
|
|
RW67-1D2-U050 | BIM OL RELAY CLASS10 32-50 | Bimetallic |
Price unavailable
|
