Specifications
| Manufacturer Part Number | EM4102T |
|---|---|
| Manufacturer | Baldor-ABB Motors |
| Product Series | M |
| Family Series | Baldor-ABB Motors Motors, M Series |
| Type | General Purpose |
| Horsepower | 20 hp |
| Speed | 1,200 RPM |
| RPM | 1,200 RPM |
| Phase | 3 |
| NEMA Frame | 286T |
| AC Voltage | 208-230 VAC, 460 VAC |
| Nominal Voltage | 208 VAC, 240 VAC, 415 VAC, 480 VAC |
| Enclosure | Totally Enclosed Fan Cooled |
| Mounting | Foot Mount, Rigid |
| Current Rating | 27 A |
| Service Factor | 1.15 |
| Inverter Duty | No |
| Composition | Cast Iron |
| Bearing Type | Ball |
| Overload Protection | None |
| Length | 27.76 " |
| H x W x D | 19.00 " x 23.75 " x 31.00 " |
| Net Weight | 420 lbs |
| Gross Weight | 420 lbs |
Description
Motors, M Series
Item #
EM4102T
20HP, 1180RPM, 3PH, 60HZ, 286T, 1054M
M Series Information
Documents & Resources Links
Alternatives
Compare available alternatives using the specifications that matter for this product.
| Image | Part | Description | Voltage | Mounting | Series | Price | Action |
|---|---|---|---|---|---|---|---|
|
170001.60 | Motor, 20HP, 208-230/460V, 1185RPM TEFC Wattsaver | 208 VAC, 240 VAC, 480 VAC | Foot Mount, Rigid | Three Phase TEFC |
Quote Required
|
|
|
HD20P3E | Motor, 20 HP, 1200 RPM, 286T | 240 VAC, 480 VAC | Foot Mount |
Price unavailable
|
Added to Cart
EM4102T Baldor-ABB Motors Motors, M Series, 20HP, 1180RPM, 3PH, 60HZ, 286T, 1054M
Series M
MFG #:
EM4102T
20HP, 1180RPM, 3PH, 60HZ, 286T, 1054M
