Specifications
Country of Origin	Czech Republic
Manufacturer Part Number	CS10.241
Manufacturer	Puls
Product Series	Dimension
Family Series	Puls Power Supplies, Dimension Series
Power	240 W
Nominal Input Voltage	120 VAC, 240 VAC
AC Voltage	100-120 VAC, 220-240 VAC
Input Frequency	47-63 Hz
Phase	1
Nominal Output Voltage	24 VDC
Output VDC	24-28 VDC
Output Current	10 A
Number of Outputs	1
Mounting	DIN Rail
Enclosed	Yes
Encapsulated	No
Output Voltage Adj.	Yes
Overvoltage Protection	Yes
Overload Protection	Yes
Short Circuit Protection	Yes
Power Factor Correction	No
Parallel Operation	No
Remote Sensing	No
Remote On/Off Control	No
Operating Temperature	-13-158 °F
Approvals	CCC, CE, cURus, UL1604 CLASS 1 DIV 2, UL508, UL60950
H x W x D	3.66 " x 5.51 " x 5.91 "
Net Weight	1.5431 lbs
Gross Weight	1.7637 lbs

Alternatives

Compare available alternatives using the specifications that matter for this product.

Alternatives comparison
Part	Description	Voltage	Mounting	Series	Price
SVL10-24-100	SVL Essential Din Rail Series, Nominal Output Voltage: 24VDC, Nominal Output Current: 10A, Max. Power: 240W, Frequency Rating: 50/60Hz, Single Phase, DIN Rail Mounting	85-264 VAC	DIN Rail	SVL	Price unavailable
1SVR427035R0000	The CP-E 24/10.0 is a power supply from the CP-E range. The primary switch mode power supply offers a wide range input of 90-132 V AC, 180-264 V AC and 210-375 V DC, rated input voltage is 115 or 230 V AC auto select. The rated output power is 240	115-230 VAC	DIN Rail	CP-E	Price unavailable
QS10.241	Power Supply, 24VDC, 10A, 1Ph, 240W, 100-240VAC Input, 24-28VDC Output, 124mmHx60mmWx117mmD, Spring Terminal	100-240 VAC	DIN Rail	Q	Price unavailable
PS6R-G24	Power Supply, 24VDC, 10A, 1Ph, 240W, 100-240VAC Input, 21.6-26.4VDC Out, 106.5mmHx60mmWx125mmD	85-264 VAC	DIN Rail	PS6R	Price unavailable
CS10.243	POWER SUPPLY, 24VDC, 10A, 1PH, 240W 100-120VAC INPUT 124mmHx60mmWx117mmD, SCREW TERMINAL	100-120 VAC	DIN Rail	Dimension	Price unavailable

Accessories

Compare compatible accessories for this product.

Accessories comparison
Part	Description	Mounting	Series	Price
YR2.DIODE	Redundancy Module, 10-60VDC, 2x10A, Decoupling Module, Y-Series, 20A Max Output Current Rating	DIN Rail	Dimension	Price unavailable
YRM2.DIODE	REDUNDANCY MODULE WITH DIAGNOSTICS	DIN Rail	Dimension	Price unavailable
ZM1.WALL	MOUNTING BRACKET, (pkg / 2pcs) FOR PANEL MTG Q SERIES POWER SUPPLY			Price unavailable
ZM13.SIDE	MOUNTING BRACKET, FOR SIDE MOUNTING Q SERIES POWER SUPPLIES			Price unavailable
